Silvertone 7172

Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1318241) Radio

Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1318242) Radio

Silvertone 7172 ; Sears, Roebuck & Co. (ID = 685377) Radio
Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336317) Radio Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336309) Radio
Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336312) Radio Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336315) Radio
Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336320) Radio Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336323) Radio
Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336326) Radio
Use red slider bar for more.
Silvertone 7172 ; Sears, Roebuck & Co. (ID = 1336317) Radio
Sears, Roebuck & Co.: Silvertone 7172 [Radio] ID = 1336317 933x841
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 7172, Sears, Roebuck & Co.; Chicago (IL):
Silvertone 7172 Front View #1

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 6D6 75 42 80
Main principle Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 110 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Silvertone 7172 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes

The Sears Silvertone 7172 is an AC operated 6 tube BC and SW band receiver.

Chassis and schematic used in this model also used in Sears Silvertone model 7184.

See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Corona Radio & Television Co., Chicago, Ill (Sears Manufacturer Source Number Code 104).

External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
Literature/Schematics (1) Rider's Perpetual, Volume 10 = 1939 and before (Riders 10-97)
Literature/Schematics (2) Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 965 to 966)
