Silvertone 2015 Ch= 132.021 Order=57G 02015

Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 539062) Radio

Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 539063) Radio

Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 539064) Radio

Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 539065) Radio
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 2275095) Radio Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 2275094) Radio
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 2275096) Radio Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1325557) Radio
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1325558) Radio Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 539061) Radio
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1344543) Radio Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1344525) Radio
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1335593) Radio Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 1402024) Radio
Use red slider bar for more.
Silvertone 2015 Ch= 132.021 Order=57G 02015; Sears, Roebuck & Co. (ID = 2275095) Radio
Sears, Roebuck & Co.: Silvertone 2015 Ch= 132.021 Order=57G 02015 [Radio] ID = 2275095 1400x802
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 2015 Ch= 132.021 Order=57G 02015, Sears, Roebuck & Co.; Chicago (IL):
American Radio Design Greg Mercurio

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1952–1956 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12SK7 12SA7 12SK7 12SQ7 35L6GT 35Z5GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Silvertone 2015 Ch= 132.021 Order=57G 02015 - Sears, Roebuck & Co.; Chicago
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 13.875 x 6.75 x 6.5 inch / 352 x 171 x 165 mm
Notes

Cabinet= Brown. See also the Silvertone model 2016 in Ivory or model 2014 in Green.

Price in first year of sale 26.95 $
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 3-53, Set 196, Folder 15)
Literature/Schematics (2) Machine Age to Jet Age II (page 260.)
Literature/Schematics (3) Sears, Roebuck Catalogs (Silvertone) (1952/53 page 855, 1953/54 page 886, 1954 page 774, 1954/55 page 918.)
Literature/Schematics (4) Sears, Roebuck Catalogs (Silvertone) (Spring & Summer 1956, page 832. Spring/Summer 1955, page 778..)

Model page created by Egon Penker. See "Data change" for further contributors.
