• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1956 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 125076

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 12AU7A 12AX7 6V6GT 6X5

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Silvertone 6070 Ch=567.34002 & Amp. Ch=567.35006 - Sears, Roebuck & Co.; Chicago

• Shape
• Tablemodel, with any shape - general.

• Notes

• The Silvertone models 3070,4070 and 6070 are designed for one speed operation. Models 3070, 4070 and 6070 record and play back at a constant speed of 3 3/4" per second. The major difference between the models is in the amplifier used. The model 6070 has a 12AU7A for the pre-amplifier where the models 3070 and 4070 have a 5879 pre-amplifier.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 310 Folder 12 3-1956)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
