Silvertone 7174 Ch= 528.52020

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434110) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434111) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434112) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434113) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434114) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434115) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434116) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434117) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434118) Television

Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434119) Television
Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434322) Television
Use red slider bar for more.
Silvertone 7174 Ch= 528.52020; Sears, Roebuck & Co. (ID = 2434322) Television
Sears, Roebuck & Co.: Silvertone 7174 Ch= 528.52020 [Television] ID = 2434322 787x1106
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 7174 Ch= 528.52020, Sears, Roebuck & Co.; Chicago (IL):
Picture from service manual.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1957 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 6BS8 or 6BZ7 6AT8 6CB6 6CB6 6AM8 6BA8 6AU6 6U8 6T8 6V6GT 6CM7 6SN7GTB 6CD6GA or 6DQ6A 6AU4GT 1B3GT 24YP4
Main principle Superhet with RF-stage
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Silvertone 7174 Ch= 528.52020 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

Silvertone model 7174 is a 24" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 528.52020 VHF tuner 95-87 and picture tube 24YP4.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 370 Folder 12 dated 9-57)

Model page created by Dirk Taekels. See "Data change" for further contributors.



All listed radios etc. from Sears, Roebuck & Co.; Chicago (IL)
Here you find 5063 models, 3055 with images and 3572 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
