Silvertone 1760 Ch= 206A or 206B
Sears, Roebuck & Co.; Chicago (IL)
- País
- Estados Unidos
- Fabricante / Marca
- Sears, Roebuck & Co.; Chicago (IL)
- Año
- 1934
- Categoría
- Radio - o Sintonizador pasado WW2
- Radiomuseum.org ID
- 55942
-
- Brand: Silvertone
Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.
- Numero de valvulas
- 8
- Principio principal
- Superheterodino en general; ZF/IF 480 kHz; 3 Etapas de AF
- Número de circuitos sintonía
- 8 Circuíto(s) AM
- Gama de ondas
- OM y OC
- Tensión de funcionamiento
- Red: Corriente alterna (CA, Inglés = AC) / Either transformer: 25 cycles, 110V or 60 cycles, 110 Volt
- Altavoz
- Altavoz electrodinámico (bobina de campo) / Ø 8 inch = 20.3 cm
- Material
- Madera
- de Radiomuseum.org
- Modelo: Silvertone 1760 Ch= 206A or 206B - Sears, Roebuck & Co.; Chicago
- Forma
- Consola baja, patas más cortas del 50%.
- Anotaciones
-
The Sears Silvertone 1760 is an AC operated 8 tube BC and SW band receiver.
Chassis using this circuit are rubber stamped 206A or 206B.
This model originally had problems with hum, and minor changes were made by changing the values of C16, R9, R10 and R11 per the notes listed in both the Sears Service Manual and the Riders manual. The production release of this model with the changes incorporated had the chassis stamped 206A or 206B. The original production release without these changes had the chassis rubber stamped 206.
See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).
- Ext. procedencia de los datos
- Ernst Erb
- Referencia esquema
- Rider's Perpetual, Volume 5 = ca. 1934 and before
- Documentación / Esquemas (1)
- Rider's Perpetual, Volume 5 = ca. 1934 and before (Riders Sears 5-27)
- Documentación / Esquemas (2)
- Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 421 to 423)
