Labor W, Tonfrequenz-Röhrenvoltmeter RV5

Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 639082) Equipment

Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 681089) Equipment

Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 681090) Equipment
Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 254321) Equipment Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 254322) Equipment
Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 964910) Equipment
Use red slider bar for more.
Labor W, Tonfrequenz-Röhrenvoltmeter RV5; Sennheiser (ID = 254321) Equipment
Sennheiser: Labor W, Tonfrequenz-Röhrenvoltmeter RV5 [Equipment] ID = 254321 906x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Labor W, Tonfrequenz-Röhrenvoltmeter RV5, Sennheiser Electronic (Labor W); Wennebostel

Country:  Germany
Manufacturer / Brand:  Sennheiser Electronic (Labor W); Wennebostel
Year: 1950 Category: Service- or Lab Equipment
Valves / Tubes 2: EAF42 EF40 STV70/6 STV150/15
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Labor W, Tonfrequenz-Röhrenvoltmeter RV5 - Sennheiser Electronic Labor W;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 260 x 195 x 95 mm / 10.2 x 7.7 x 3.7 inch
Notes

Messbereiche: 6/20/60/200/600 mV, 2/6/20/60/200/600 V. Zusätzlich NF-Verfolger (externer LS oder Kopfhörer nötig).

Das Tonfrequenz-Röhrenvoltmeter RV5 wurde im Rahmen des Artikels "Aus der Arbeit des Labor W." in der A.R.T., August 1950, auf S. 231 vorgestellt.

Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Collectors' prices
Mentioned in Die Allgemeine Rundfunk-Technik (8/1950, S.230f.)

Model page created by Willi Ribbe. See "Data change" for further contributors.



All listed radios etc. from Sennheiser Electronic (Labor W); Wennebostel
Here you find 277 models, 260 with images and 122 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
