• Year
  • 1959
  • Category
  • Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
  • Radiomuseum.org ID
  • 187865
    • Brand: Doraphone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 23
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • from Radiomuseum.org
  • Model: 27L159 Ch= 159 - Setchell Carlson, Inc.; St.
  • Notes
  • 21" b/w TV with US standard VHF Tuner Channels 2 thru 13. Some Models with Picture Tube 24AEP4 or 27VP4.
    Some Models show a Receiver AM/FM, and Phono Stereo Amp and Record Changer available.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
