27L159 Ch= Z159

27L159 Ch= Z159; Setchell Carlson, (ID = 892032) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892033) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892034) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892035) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892036) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892037) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892038) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892039) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892040) TV Radio

27L159 Ch= Z159; Setchell Carlson, (ID = 892041) TV Radio
Use red slider bar for more.
27L159 Ch= Z159; Setchell Carlson, (ID = 892032) TV Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Setchell Carlson, Inc.; St.Paul (MN)
Brand

Doraphone
Year: 1959 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 23: 21CBP4A
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 27L159 Ch= Z159 - Setchell Carlson, Inc.; St.
Notes 21" b/w TV with US standard VHF Tuner Channels 2 thru 13. Some Models with Picture Tube 24AEP4 or 27VP4.
Some Models show a Receiver AM/FM, and Phono Stereo Amp and Record Changer available.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 6-59, Set 445, Folder 2)

Model page created by Egon Penker. See "Data change" for further contributors.
