For model 71 Ch= C-201, Setchell Carlson, Inc.; St.Paul (MN):
Original-Prospect

Country:  United States of America (USA)
Manufacturer / Brand:  Setchell Carlson, Inc.; St.Paul (MN)
Brand

Doraphone
Year: 1957 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 18: 21ATP4
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 71 Ch= C-201 - Setchell Carlson, Inc.; St.
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 20.13 x 18.75 x 18.13 inch / 511 x 476 x 461 mm
Notes Setchell Carlson 71, "Unit-Ized" chassis= C-201;
20.13" b/w TV with US standard VHF tuner & AM radio.
Cabinet in rubbed blond oak or genuine mahogany, optional brass finished legs.
Correct tube quantity unknown.
Source of data -- Original prospect or advert

Model page created by a member from A. See "Data change" for further contributors.
