T60 Ch= 259

T60 Ch= 259; Setchell Carlson, (ID = 552324) Television

T60 Ch= 259; Setchell Carlson, (ID = 552325) Television

T60 Ch= 259; Setchell Carlson, (ID = 552326) Television
T60 Ch= 259; Setchell Carlson, (ID = 552323) Television
Use red slider bar for more.
T60 Ch= 259; Setchell Carlson, (ID = 552323) Television
Setchell Carlson,: T60 Ch= 259 [Television] ID = 552323 430x415
Select picture or schematic to display from thumbnails on the right and click for download.
For model T60 Ch= 259, Setchell Carlson, Inc.; St.Paul (MN):
Sams photofact.

Country:  United States of America (USA)
Manufacturer / Brand:  Setchell Carlson, Inc.; St.Paul (MN)
Brand

Doraphone
Year: 1959 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 6BC8 6CL8 6BZ6 6BZ6 6AW8A 6BZ6 6BN8 6AQ5 6BE6 12AU7A 6CM6 12AU7A 6DQ6A 6AX4GT 1G3GT 21CBP4A
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: T60 Ch= 259 - Setchell Carlson, Inc.; St.
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes Channels 2 thru 13 VHF: Sams photofact set 471 folder 2 date 1-60 features the Setchel Carlson models T60 and 60C as the same schematic.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 471 folder 2 date 1-60)

Model page created by Peter Hoddow. See "Data change" for further contributors.
