43ZZ3453 /16B Ch= Anubis A

Radiola (marque)

Data
Forum
Pictures
Collections

  • Year
  • 1991
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 254466
    • Brand: SFER

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 220-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 43ZZ3453 /16B Ch= Anubis A - Radiola marque
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 410 x 390 x 430 mm / 16.1 x 15.4 x 16.9 inch
  • Notes

  • Model also known for other destination countries or with other brand names as:

    43ZZ3453 /03B /06B /08B /09B /10B /11B /13B /22B /26B /31B

    Tuner:

    • /06, /26 : PAL B/G/I, SECAM B/G/L/L'
    • all others: PAL B/G

    • VHF a, 46 - 118 MHz
    • VHF b, 118 - 300 MHz
    • UHF, 470 - 861 MHz
    • /26, /31: additional Hyperband, 300 - 470 MHz

    Remote control: RC9020, RC9041 for /08.

    Made in Italy.

  • Net weight (2.2 lb = 1 kg)
  • 13 kg / 28 lb 10.1 oz (28.634 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Manuel Albano Neves. See "Data change" for further contributors.
