Combiné RA42A

Combiné RA42A; Radiola marque (ID = 2527524) Radio

Combiné RA42A; Radiola marque (ID = 2527525) Radio

Combiné RA42A; Radiola marque (ID = 2527526) Radio

Combiné RA42A; Radiola marque (ID = 2527527) Radio

Combiné RA42A; Radiola marque (ID = 2527528) Radio

Combiné RA42A; Radiola marque (ID = 2527529) Radio

Combiné RA42A; Radiola marque (ID = 2527530) Radio

Combiné RA42A; Radiola marque (ID = 2527531) Radio
Use red slider bar for more.
Combiné RA42A; Radiola marque (ID = 2527524) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Combiné RA42A - Radiola marque
Notes

Poste combiné, type 42 A., 4 lampes, 1 valve.

Données préliminaires. L'appareil est répertorié dans la "Liste d'appareils de radiophonie reconnus de bonne qualité [...]" - la liste ne mentionne le nom / type et le nombre de tubes.

Mentioned in Bulletin de l'Instruction Primaire de la Vendée, Jan-Fév 1937, p.103

Model page created by Mark Hippenstiel. See "Data change" for further contributors.



All listed radios etc. from Radiola (marque)
Here you find 823 models, 514 with images and 249 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
