RA401T

RA401T; Radiola marque (ID = 1839831) Radio

RA401T; Radiola marque (ID = 1839832) Radio

RA401T; Radiola marque (ID = 1839833) Radio

RA401T; Radiola marque (ID = 1839834) Radio

RA401T; Radiola marque (ID = 1839835) Radio

RA401T; Radiola marque (ID = 1839836) Radio

RA401T; Radiola marque (ID = 1839837) Radio
RA401T; Radiola marque (ID = 1839827) Radio
Use red slider bar for more.
RA401T; Radiola marque (ID = 1839827) Radio
Radiola marque: RA401T [Radio] ID = 1839827 800x695
Select picture or schematic to display from thumbnails on the right and click for download.
For model RA401T, Radiola (marque):
Dépliant Gamme 1961

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: OC170 or. 2N371 OC45 OC45 OC75 OC75 OC74 OC74 OA79 OA85
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 6 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: RA401T - Radiola marque
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 311 x 212 x 101 mm / 12.2 x 8.3 x 4 inch
Notes

4 gammes d'ondes:

  • PO: 185 - 580 m
  • OC1: 13,7 - 26 m
  • OC2: 30,5 - 64.5 m
  • OC3: 77 - 187 m

Haut-parleur type AD3500HWZ. Clavier 7 touches.

Lampe de cadran: type 7994N (7,2V / 100mA, bajonet)

Le dépliant ne mentionne pas la diode OA85. En outre, il a des dimensions légèrement différentes de 316 x 215 x 112 mm.

Mentioned in -- Original-techn. papers.
Literature/Schematics (1) -- Original prospect or advert (Dépliant Gamme 1961)

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
