• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1978/1979

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 185281

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Amplifier SM-1122H - Sharp; Osaka

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 390 x 142 x 257 mm / 15.4 x 5.6 x 10.1 inch

• Notes
• Sharp SM-1122H Amplifier;
  2 x 20/30 W.
  Teil des Sharp Live 2200 Stereo-Komponenten-System.

• Net weight (2.2 lb = 1 kg)
• 5.5 kg / 12 lb 1.8 oz (12.115 lb)

• Mentioned in
• -- Original prospect or advert ((A) Kapsch Geräteprogramm 1978/79 mit Sharp Importgeräteteil)
