For model BX-327, Sharp; Osaka

Country:  Japan
Manufacturer / Brand:  Sharp; Osaka
alternative name

Hayakawa Electric Co.Ltd.
Year: 1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA352 2SA351 2SA12 2SA12 2SB75 2SB75 2SB77 2SB77 1N34A
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / AA: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch
Power out 0.21 W (max.)
from Radiomuseum.org Model: BX-327 - Sharp; Osaka
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 155 x 95 x 45 mm / 6.1 x 3.7 x 1.8 inch
Notes Sharp BX-327 Transistor Eight 2 Band;
SW: 3.9 - 12 MHz, AM: 535 - 1605 KHz, telescopic antenna, earphones jack.
Net weight (2.2 lb = 1 kg) 0.520 kg / 1 lb 2.3 oz (1.145 lb)
Source of data - - Data from my own collection

Model page created by Santiago Lopez-Zapatero. See "Data change" for further contributors.
