Eight Transistor BX-389

Eight Transistor BX-389; Sharp; Osaka (ID = 639005) Radio

Eight Transistor BX-389; Sharp; Osaka (ID = 639009) Radio

Eight Transistor BX-389; Sharp; Osaka (ID = 639013) Radio

Eight Transistor BX-389; Sharp; Osaka (ID = 639015) Radio
Eight Transistor BX-389; Sharp; Osaka (ID = 1250972) Radio Eight Transistor BX-389; Sharp; Osaka (ID = 639018) Radio
Eight Transistor BX-389; Sharp; Osaka (ID = 1250973) Radio Eight Transistor BX-389; Sharp; Osaka (ID = 1250975) Radio
Eight Transistor BX-389; Sharp; Osaka (ID = 1250978) Radio Eight Transistor BX-389; Sharp; Osaka (ID = 1250980) Radio
Use red slider bar for more.
Eight Transistor BX-389; Sharp; Osaka (ID = 1250972) Radio
Sharp; Osaka: Eight Transistor BX-389 [Radio] ID = 1250972 863x601
Select picture or schematic to display from thumbnails on the right and click for download.
For model Eight Transistor BX-389, Sharp; Osaka:
auctions.yahoo.co.jp by user ia_kurazou h164004398

Country:  Japan
Manufacturer / Brand:  Sharp; Osaka
alternative name

Hayakawa Electric Co.Ltd.
Year: 1965 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA352 2SA12 2SA12 1N34A 2SB75 2SB75 2SB77 2SB77 2SB351
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.62 inch = 6.7 cm
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: Eight Transistor BX-389 - Sharp; Osaka
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Sharp 2Band 8 Transistor Portable Radio Model Eight Transistor BX-389.
Tuning Range: AM 530 - 1650 kHz, SW 3,9 - 12 MHz
Earphone Jack, Telescopic antenna.


Collectors' prices
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
