• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 157301

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (not changer)

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Power out
• 0.35 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: FXG-700 - Sharp; Osaka

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 9.75 x 5.75 x 2.75 inch / 248 x 146 x 70 mm

• Net weight (2.2 lb = 1 kg)
• 1.680 kg / 3 lb 11.2 oz (3.7 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Antonio Barros-Regada. See "Data change" for further contributors.
