GS-5500

Sharp; Osaka

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 129369
    • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 24
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 5 AM circuit(s)     7 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Record Player (perh.Changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 24 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: GS-5500 - Sharp; Osaka
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Stereo-Gerät mit eingebautem Plattenwechsler, 4 Geschwindigkeiten; Lautsprecher-Boxen im Lieferumfang.

    Stereo equipment with built-in disk changer, 4 speeds; speakers included.
  • Mentioned in
  • Original Sharp Service Unterlagen
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
