Optonica Stereo Tuner ST-1515HB

Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248112) Radio Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248111) Radio
Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248106) Radio Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248110) Radio
Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248113) Radio Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248107) Radio
Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248108) Radio Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248109) Radio
Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248114) Radio Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248115) Radio
Use red slider bar for more.
Optonica Stereo Tuner ST-1515HB; Sharp; Osaka (ID = 2248112) Radio
Sharp; Osaka: Optonica Stereo Tuner ST-1515HB [Radio] ID = 2248112 1400x722
Select picture or schematic to display from thumbnails on the right and click for download.
For model Optonica Stereo Tuner ST-1515HB, Sharp; Osaka

Country:  Japan
Manufacturer / Brand:  Sharp; Osaka
alternative name

Hayakawa Electric Co.Ltd.
Year: 1978/1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Optonica Stereo Tuner ST-1515HB - Sharp; Osaka
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 408 x 144 x 275 mm / 16.1 x 5.7 x 10.8 inch
Notes

Sharp FM/AM Stereo Tuner Model Optonica ST-1515HB.

Tuning Ranges:
FM: 87.6 - 108 MHz
AM: 520 - 1620 kHz

Signal- and tuning meters. FM muting circuit,
Hi-Blend, AC outlet unswitched 220/240 V 50/60 Hz, max. Power Consumption 10 Watts.
Wooden Side Panels.
Superheterodyne system, with PLL Stereo Demodulator,
Air check calibrator circuit (400 Hz).
8 TR, 3 IC, 1 FET.

See also model ST-1515H (probably identical except for the color of the front cover).


Net weight (2.2 lb = 1 kg) 4.3 kg / 9 lb 7.5 oz (9.471 lb)
Source of data -- Original-techn. papers.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
