Super Sensitive FM/AM Portable Radio FX-213X
Use red slider bar for more.
Sharp; Osaka: Super Sensitive FM/AM Portable Radio FX-213X [Radio] ID = 1072269 675x900
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Hayakawa Electric Co.Ltd. | ||||
|---|---|---|---|---|---|
| Year: 1978 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast (BC) and FM or UHF. |
| Details | |
| Power type and voltage | Dry Batteries |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | |
| from Radiomuseum.org | Model: Super Sensitive FM/AM Portable Radio FX-213X - Sharp; Osaka |
| Material | Plastics (no bakelite or catalin) |
| Shape | Very small Portable or Pocket-Set (Handheld) < 8 inch. |
| Notes | Sharp Super Sensitive FX-213X; Tuning indicator LED, earphones jack, wrist strap. |
Model page created by a member from A. See "Data change" for further contributors.
