WQ-T222H

• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1988 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 328234

• • alternative name: Hayakawa Electric Co.Ltd.

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• 2SC1815 2SC1815 2SC1815 2SC2001 2SC1815 2SA1015 2SC1815 2SC1815

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110- 120/240-240 or 6 x 1.5 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 6.8 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: WQ-T222H - Sharp; Osaka

• Dimensions (WHD)
• 502 x 155 x 133 mm / 19.8 x 6.1 x 5.2 inch

• Notes

• Integrated circuits are incorporated:

  TA7378P, TA8110AP, TA7343AP, BA3416BL, BA3312N, and TA7769P.

• Net weight (2.2 lb = 1 kg)
• 2.9 kg / 6 lb 6.2 oz (6.388 lb)

• Author
• Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
