23G; Siemens; D S.& (ID = 1412282) Radio
Siemens; D S.&: 23G [Radio] ID = 1412282 933x773
Select picture or schematic to display from thumbnails on the right and click for download.
For model 23G, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: RENS1820 RENS1823d
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Direct Current supply (DC) / 110-220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: 23G - Siemens; D S.& Halske / S.
Material Bakelite case
Dimensions (WHD) 284 x 205 x 160 mm / 11.2 x 8.1 x 6.3 inch
Notes

Halbkreisförmige «Riesenskala».

Siehe auch Paralleltype Telefunken 122G mit anderem Gehäuse.

Price in first year of sale 125.00 RM !
Source of data Katalog Radio-Zentrale Prohaska 1932/33 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
