For model Club RM 605, Siemens; D (S.& Halske / S. Electrogeräte):
aus siemenskatalog 1981

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1990 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12:
Main principle Superheterodyne (common); ZF/IF 495/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220/6x1,5 Volt
Loudspeaker 2 Loudspeakers
Power out 3.6 W (unknown quality)
from Radiomuseum.org Model: Club RM 605 - Siemens; D S.& Halske / S.
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 330 x 156 x 75 mm / 13 x 6.1 x 3 inch
Notes

6 IC; NF-Ausgangsleistung 2x1,8 Watt, Anschlüsse: Außenlautsprecher 3,2-6 Ohm Mikrofonimpedanz extern 5,9 kOhm

Farbe: Braun ( Front ist Silber).

Mentioned in Original Siemens Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
