Siemens; D S.&: Club RM 716 [Radio] ID = 807058 850x496
Select picture or schematic to display from thumbnails on the right and click for download.
For model Club RM 716, Siemens; D (S.& Halske / S. Electrogeräte):
By courtesy of guest Michael Francis, Dublin, Ireland.

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1978 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 24:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / AC 220 / D : 6 x 1,5 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Club RM 716 - Siemens; D S.& Halske / S.
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 420 x 250 x 120 mm / 16.5 x 9.8 x 4.7 inch
Notes The Siemens Club RM 716 black stereo radio cassette recorder uses 4 IC, SANYO technology.
Net weight (2.2 lb = 1 kg) 5.250 kg / 11 lb 9 oz (11.564 lb)
Mentioned in Original Siemens Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.



All listed radios etc. from Siemens; D (S.& Halske / S. Electrogeräte)
Here you find 2449 models, 2024 with images and 1272 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Siemens; D S.&: Club RM 716
Threads: 1 | Posts: 1
Hits: 1181     Replies: 0
siemens: RM 716; Club, Chassis - Ausbau
Ottmar Lauth
16.Jan.16
  1

Die Infos ( " Chassis - Ausbau ") sind sehr wichtig.

Damit man jedoch das Chassis aus dem Gehäuse entfernen kann, muß man aber  außerdem die 4 Drähte ablöten, die von der unteren linken Ecke der NF - Platine  zu den beiden Hochtönern führen.

Beim 'Wiedereinbau ist darauf zu achten, dass diese 4 Drähte wieder an die richtigen Stellen angelötet werden.Diese sind mit englischen Abkürzungen beschriftet :

B = Blue = Blau, W = White = Weiß,G = Grey = Grau und Y = Yellow = Gelb.
