- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1930 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 5378
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 1.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Elv816 - Siemens & Halske, -Schuckert
- Dimensions (WHD)
- 460 x 230 x 150 mm / 18.1 x 9.1 x 5.9 inch
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Source of data
- Radiokatalog Band 1, Ernst Erb
- Circuit diagram reference
- Lange-Nowisch
- Mentioned in
- - - Manufacturers Literature (Siemens Verstärker und Zubehör, Code 5.30.19.Ruf. Mai 1930)
