High Fidelity 510

High Fidelity 510; Siemens-Austria WSW; (ID = 1884356) Ampl/Mixer High Fidelity 510; Siemens-Austria WSW; (ID = 1884349) Ampl/Mixer
High Fidelity 510; Siemens-Austria WSW; (ID = 1884350) Ampl/Mixer High Fidelity 510; Siemens-Austria WSW; (ID = 1884351) Ampl/Mixer
High Fidelity 510; Siemens-Austria WSW; (ID = 1884352) Ampl/Mixer High Fidelity 510; Siemens-Austria WSW; (ID = 1884353) Ampl/Mixer
High Fidelity 510; Siemens-Austria WSW; (ID = 1884354) Ampl/Mixer High Fidelity 510; Siemens-Austria WSW; (ID = 1884355) Ampl/Mixer
Use red slider bar for more.
High Fidelity 510; Siemens-Austria WSW; (ID = 1884356) Ampl/Mixer
Siemens-Austria WSW;: High Fidelity 510 [Ampl/Mixer] ID = 1884356 1400x637
Select picture or schematic to display from thumbnails on the right and click for download.
For model High Fidelity 510, Siemens-Austria (WSW); Wien

Country:  Austria
Manufacturer / Brand:  Siemens-Austria (WSW); Wien
alternative name

Ges. für Technische Glaswaren
Brand
Wiener Schwachstrom Werke (WSW)
Year: 1956 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: EF86 EF86 EF86 EL84 EL84 EZ81
Main principle Audio-Amplification
Wave bands - without
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 15 W (unknown quality)
from Radiomuseum.org Model: High Fidelity 510 - Siemens-Austria WSW; Wien
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 260 x 87 x 90 mm / 10.2 x 3.4 x 3.5 inch
Notes

HiFi-Mono Gegentaktverstärker.
Eingänge: Mikrofon, Plattenspieler, Radio und Tonband (Eingänge über Koaxbuchsen). Getrennte Höhen / Tiefenregler. Abmessungen des Vorverstärkers: 260 x 87 x 90 mm. Abmessungen des Endverstärkers: 340 x 120 x 145 mm. Gewicht des Vorverstärkers: 1,4 kg. Gewicht des Endverstärkers: 4,8 kg. Skalenlampe 10V / 0,2A.
Die Verstärkeranlage wird mit dem Volume-Regler ein / ausgeschalten.

Net weight (2.2 lb = 1 kg) 6.2 kg / 13 lb 10.5 oz (13.656 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
