• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1961

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 91609

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• DG7-6

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Kathodenstrahl-Relaisprüfer 9T.mse.109a - Siemens & Halske, -Schuckert

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 265 x 180 x 190 mm / 10.4 x 7.1 x 7.5 inch

• Notes
• Dient zur optischen Darstellung der Prellung und dem Messen und Einstellen von Telegraphenrelais; Vorsteckwiderstände als Zubehör.

• Net weight (2.2 lb = 1 kg)
• 7.3 kg / 16 lb 1.3 oz (16.079 lb)

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
