Lichtmarken-Galvanometer 1.5 mV & 30 mV

Lichtmarken-Galvanometer 1.5 mV & 30 mV; Siemens; D S.& (ID = 988183) Equipment Lichtmarken-Galvanometer 1.5 mV & 30 mV; Siemens; D S.& (ID = 2511257) Equipment
Use red slider bar for more.
Lichtmarken-Galvanometer 1.5 mV & 30 mV; Siemens; D S.& (ID = 988183) Equipment
Siemens; D S.&: Lichtmarken-Galvanometer 1.5 mV & 30 mV [Equipment] ID = 988183 933x787
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lichtmarken-Galvanometer 1.5 mV & 30 mV, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1940 ?? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit. / 6 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Lichtmarken-Galvanometer 1.5 mV & 30 mV - Siemens; D S.& Halske / S.
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 240 x 190 x 140 mm / 9.4 x 7.5 x 5.5 inch
Notes Siemens Lichtmarken-Galvanometer, 2 Messeingänge: 1,5 und 30 mV Vollausschlag.
Innenwiderstand 350 Ω und 12,8 kΩ. Grosse Skala mit Einteilung 0...150.
Auflösung: 10 µV/Teilstrich im 1,5 mV-Bereich, 0,2 mV/Teil bei 30 mV.

Millivoltmètre à index lumineux.
2 gammes: 1.5 mV DC fin d'échelle, Ri= 350 Ω. 30mV DC fin d'échelle, Ri= 12.8 kΩ.
Large scala graduée de 0 à 150.
Sur l'entrée 1.5 mV, résolution de 10 µV/graduation.
Sur l'entrée 30 mV, résolution de 0.2 mV/graduation.
Net weight (2.2 lb = 1 kg) 3.250 kg / 7 lb 2.5 oz (7.159 lb)

Model page created by Jean Marchal. See "Data change" for further contributors.
