PF13

PF13; Siemens; D S.& (ID = 331778) TV Radio

PF13; Siemens; D S.& (ID = 331779) TV Radio

PF13; Siemens; D S.& (ID = 331780) TV Radio

PF13; Siemens; D S.& (ID = 331781) TV Radio

PF13; Siemens; D S.& (ID = 331782) TV Radio
PF13; Siemens; D S.& (ID = 295332) TV Radio PF13; Siemens; D S.& (ID = 1395187) TV Radio
Use red slider bar for more.
PF13; Siemens; D S.& (ID = 295332) TV Radio
Siemens; D S.&: PF13 [TV Radio] ID = 295332 656x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model PF13, Siemens; D (S.& Halske / S. Electrogeräte):
Q: Siemens Service

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1960/1961 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details Changer (Record changer); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: PF13 - Siemens; D S.& Halske / S.
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 1350 x 900 x 500 mm / 53.1 x 35.4 x 19.7 inch
Notes Fernseh-Chassis = FT205;
Rundfunk-Chassis = H8 Stereo;
Phono-Chassis = Dual 1007.
Net weight (2.2 lb = 1 kg) 89 kg / 196 lb 0.6 oz (196.035 lb)
Price in first year of sale 1'948.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1960/61

Model page created by Bernd P. Kieck. See "Data change" for further contributors.



All listed radios etc. from Siemens; D (S.& Halske / S. Electrogeräte)
Here you find 2451 models, 2026 with images and 1274 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
