planar RK411; Siemens; D S.& (ID = 1888776) Radio
Siemens; D S.&: planar RK411 [Radio] ID = 1888776 1400x1478
Select picture or schematic to display from thumbnails on the right and click for download.
For model planar RK411, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1974–1977 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SC668 2SC930 2SC929 2SC930 2SC1173 2SC1173 2SC1383 2SB176 µPC27
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: planar RK411 - Siemens; D S.& Halske / S.
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 300 x 180 x 50 mm / 11.8 x 7.1 x 2 inch
Notes

Die technische Unterlage nennt 9 Transistoren, jedoch sind auf dem Schaltplan nur 8 Transistoren zu finden.

Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)
External source of data Erb
Source of data Katalog RFP 1974
Mentioned in Handbuch VDRG 1975/1976 (und 1976/77)
