TURF special RK331

TURF special RK331; Siemens; D S.& (ID = 66134) Radio

TURF special RK331; Siemens; D S.& (ID = 66135) Radio

TURF special RK331; Siemens; D S.& (ID = 551343) Radio

TURF special RK331; Siemens; D S.& (ID = 551344) Radio

TURF special RK331; Siemens; D S.& (ID = 551345) Radio
TURF special RK331; Siemens; D S.& (ID = 1312407) Radio TURF special RK331; Siemens; D S.& (ID = 94484) Radio
TURF special RK331; Siemens; D S.& (ID = 1009817) Radio TURF special RK331; Siemens; D S.& (ID = 1009818) Radio
TURF special RK331; Siemens; D S.& (ID = 1009819) Radio TURF special RK331; Siemens; D S.& (ID = 1312843) Radio
TURF special RK331; Siemens; D S.& (ID = 1312844) Radio TURF special RK331; Siemens; D S.& (ID = 1312846) Radio
TURF special RK331; Siemens; D S.& (ID = 1312848) Radio TURF special RK331; Siemens; D S.& (ID = 1312849) Radio
Use red slider bar for more.
TURF special RK331; Siemens; D S.& (ID = 1312407) Radio
Siemens; D S.&: TURF special RK331 [Radio] ID = 1312407 933x823
Select picture or schematic to display from thumbnails on the right and click for download.
For model TURF special RK331, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1972–1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: TURF special RK331 - Siemens; D S.& Halske / S.
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 248 x 138 x 68 mm / 9.8 x 5.4 x 2.7 inch
Notes Automatische Umschaltung von Batterie- auf Netzbetrieb.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
External source of data Erb
Source of data Handbuch VDRG 1972/1973


All listed radios etc. from Siemens; D (S.& Halske / S. Electrogeräte)
Here you find 2456 models, 2030 with images and 1278 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
