8432/30

8432/30; Siera; Belgien (ID = 1095776) Radio

8432/30; Siera; Belgien (ID = 1095777) Radio

8432/30; Siera; Belgien (ID = 1095778) Radio

8432/30; Siera; Belgien (ID = 1095779) Radio

8432/30; Siera; Belgien (ID = 1095780) Radio

8432/30; Siera; Belgien (ID = 1095781) Radio

8432/30; Siera; Belgien (ID = 1095782) Radio

8432/30; Siera; Belgien (ID = 1095783) Radio

8432/30; Siera; Belgien (ID = 1095784) Radio

8432/30; Siera; Belgien (ID = 1095785) Radio
8432/30; Siera; Belgien (ID = 1095775) Radio
Use red slider bar for more.
8432/30; Siera; Belgien (ID = 1095775) Radio
Siera; Belgien: 8432/30 [Radio] ID = 1095775 350x290
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8432/30, Siera; Belgien:
service manual

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 16: BF495 BF495 BF494 BF495 AC128 BC549 BC549 BC548 AC127 AC128 AC127 AC128 AC188 AC187 AC128 AC127
Main principle Superhet with RF-stage; ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 220 / 6x1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 8432/30 - Siera; Belgien
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Notes Versions /00, /13, /29, /30 and /33 use an IF of 452 kc. Version /16 is equipped for 460 kc.
Source of data -- Original-techn. papers.
Literature/Schematics (1) Service Manual

Model page created by Dirk Taekels. See "Data change" for further contributors.
