S151U; Siera; Eindhoven NL (ID = 1933036) Radio

S151U; Siera; Eindhoven NL (ID = 1933037) Radio

S151U; Siera; Eindhoven NL (ID = 1933039) Radio

S151U; Siera; Eindhoven NL (ID = 1933040) Radio

S151U; Siera; Eindhoven NL (ID = 1933041) Radio

S151U; Siera; Eindhoven NL (ID = 1933042) Radio

S151U; Siera; Eindhoven NL (ID = 1933043) Radio

S151U; Siera; Eindhoven NL (ID = 1933045) Radio

S151U; Siera; Eindhoven NL (ID = 1933046) Radio

S151U; Siera; Eindhoven NL (ID = 1933047) Radio
S151U; Siera; Eindhoven NL (ID = 1933050) Radio S151U; Siera; Eindhoven NL (ID = 1933051) Radio
S151U; Siera; Eindhoven NL (ID = 1933052) Radio S151U; Siera; Eindhoven NL (ID = 1933053) Radio
Use red slider bar for more.
S151U; Siera; Eindhoven NL (ID = 1933050) Radio
Siera; Eindhoven NL: S151U [Radio] ID = 1933050 944x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model S151U, Siera; Eindhoven (NL):
from elforum.ro

Country:  Netherlands
Manufacturer / Brand:  Siera; Eindhoven (NL)
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH3 EF9 EBC3 CL4 CY1 C9
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s); Export model
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: S151U - Siera; Eindhoven NL
Material Bakelite case
Shape Tablemodel, low profile (big size).
Notes
Tuning scale light bulbs type: 8092 (10V, 200mA).
Loudspeaker Philips type 9676 or 9648. No connectors for extarnal loudspeaker or pick-up.

This model is comparable with Jura J151U and Philips 493U-06.

Attention: Mains connected to the chassis !
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Dirk Bladt. See "Data change" for further contributors.
