S229B

S229B; Siera; Belgien (ID = 1186640) Radio S229B; Siera; Belgien (ID = 1186641) Radio
S229B; Siera; Belgien (ID = 1186642) Radio S229B; Siera; Belgien (ID = 1186643) Radio
S229B; Siera; Belgien (ID = 1186644) Radio S229B; Siera; Belgien (ID = 1186646) Radio
S229B; Siera; Belgien (ID = 1186651) Radio S229B; Siera; Belgien (ID = 1186654) Radio
S229B; Siera; Belgien (ID = 1186655) Radio
Use red slider bar for more.
S229B; Siera; Belgien (ID = 1186640) Radio
Siera; Belgien: S229B [Radio] ID = 1186640 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model S229B, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1948 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: DK32 DF33 DAC32 DF33 DL33 DL33
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 1,5 or 2 & 90-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: S229B - Siera; Belgien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Notes

Important: In case of filament supply with a 2 Volt storage battery, the connector with the 1,7Ω resistor must be used. See technical manual with equivalent Philips BG474B.



Model page created by Patrick Marinus. See "Data change" for further contributors.
