SA1009U

Siera; Belgien

  • Year
  • 1956 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 125066

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • AC/DC-set / 110-127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
  • Power out
  • 3 W (unknown quality)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: SA1009U - Siera; Belgien
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 326 x 198 x 155 mm / 12.8 x 7.8 x 6.1 inch
  • Net weight (2.2 lb = 1 kg)
  • 2.7 kg / 5 lb 15.2 oz (5.947 lb)
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by Jozef Brughmans †. See "Data change" for further contributors.
