SA7243T
Siera; Belgien
- Country
- Belgium
- Manufacturer / Brand
- Siera; Belgien
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 256438
- Number of Transistors
- 10
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Batteries / addl. power jack / 4 x 1,5 / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SA7243T - Siera; Belgien
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 320 x 190 x 95 mm / 12.6 x 7.5 x 3.7 inch
- Notes
-
FM AFC. Tone control.
Separate AM & FM tuning.See also Radio Dux Symfonica SA7243T and Radiola RA7243T.
- Author
- Model page created by a member from A. See "Data change" for further contributors.
