SA2057U

SA2057U; Siera; Belgien (ID = 498439) Radio SA2057U; Siera; Belgien (ID = 498442) Radio
SA2057U; Siera; Belgien (ID = 498443) Radio SA2057U; Siera; Belgien (ID = 498441) Radio
SA2057U; Siera; Belgien (ID = 799627) Radio SA2057U; Siera; Belgien (ID = 498444) Radio
SA2057U; Siera; Belgien (ID = 498445) Radio SA2057U; Siera; Belgien (ID = 498446) Radio
SA2057U; Siera; Belgien (ID = 944288) Radio SA2057U; Siera; Belgien (ID = 944289) Radio
Use red slider bar for more.
SA2057U; Siera; Belgien (ID = 498439) Radio
Siera; Belgien: SA2057U [Radio] ID = 498439 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model SA2057U, Siera; Belgien:
Front view

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH81 UF89 UBC81 UL84 UM80 UY42
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 110-117; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: SA2057U - Siera; Belgien
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 330 x 170 x 190 mm / 13 x 6.7 x 7.5 inch
Notes 2 dial bulb refª 8089D 00 = 12 Volt / 0,1 Ampere
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)

Model page created by Carlos Alves. See "Data change" for further contributors.
