Serenader 5064
Simpson Co. Ltd., The Robert (Simpson's); (where?)
- Country
- Canada
- Manufacturer / Brand
- Simpson Co. Ltd., The Robert (Simpson's); (where?)
- Year
- 1950 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 294289
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 110 to 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Serenader 5064 - Simpson Co. Ltd., The Robert
- Shape
- Console with any shape - in general
- Notes
-
The Serenader 5064 is a 9-tube combination radio / record changer console with eye tube. Covers standard broadcast and 9 to 18 MHz shortwave. For 25 or 60 Hz depending on nameplate rating.
Made by Dominion Electrohome Ltd for Simpsons.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Supplement 23 pages 26 and 30.)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
