S338

S338; Sobell Ind., Slough (ID = 2294366) Radio

S338; Sobell Ind., Slough (ID = 2294367) Radio

S338; Sobell Ind., Slough (ID = 2294368) Radio

S338; Sobell Ind., Slough (ID = 2294369) Radio
Use red slider bar for more.
S338; Sobell Ind., Slough (ID = 2294366) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Sobell Ind., Slough
Year: 1969 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: S338 - Sobell Ind., Slough
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Socket for earphone. Similar to the GEC G838 model.

Literature/Schematics (1) ERT Service Chart 1742

Model page created by Howard Craven. See "Data change" for further contributors.
