Sobellette 439 beige

Sobellette 439; Sobell Ind., Slough (ID = 2275568) Radio

Sobellette 439; Sobell Ind., Slough (ID = 2275569) Radio

Sobellette 439; Sobell Ind., Slough (ID = 137032) Radio

Sobellette 439; Sobell Ind., Slough (ID = 137057) Radio

Sobellette 439; Sobell Ind., Slough (ID = 546978) Radio

Sobellette 439; Sobell Ind., Slough (ID = 546979) Radio
Use red slider bar for more.
Sobellette 439; Sobell Ind., Slough (ID = 2275568) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Sobell Ind., Slough
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 14S7 12J7GT 35L6GT 35Z4GT
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Sobellette 439 [beige] - Sobell Ind., Slough
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 9 x 8.5 x 7 inch / 229 x 216 x 178 mm
Notes Single IF transformer with preset reaction, and screen grid manual volume control. Toaster style case. Available in brown bakelite or painted light green, metallic green, beige, or cream.
Source of data Radio! Radio!
Literature/Schematics (1) Radio And Television Servicing books (R&TVS)
Literature/Schematics (2) Trader Sheet 939

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
