• Country
• Italy

• Manufacturer / Brand
• Solaphon - Phonsola; Stock Radio; Milano

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 284955

• Number of Tubes
• 5

• Valves / Tubes
• 6A8G 6K7G 6Q7G 6V6G 5Y3G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 140; 160; 220; 260 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 22 cm = 8.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Sconosciuto - Unknown 1 - Solaphon - Phonsola; Stock

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 640 x 340 x 270 mm / 25.2 x 13.4 x 10.6 inch

• Net weight (2.2 lb = 1 kg)
• 10.9 kg / 24 lb 0.1 oz (24.009 lb)

• Author
• Model page created by Roberto Gabba. See "Data change" for further contributors.

• Other Models

• Here you find 29 models, 13 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
