Limitador Automático de Audio (Limiter) 250-LA
Solidyne; Buenos Aires
- Country
- Argentina
- Manufacturer / Brand
- Solidyne; Buenos Aires
- Year
- 1978 ??
- Category
- Miscellaneous (Other, Various) - see notes
- Radiomuseum.org ID
- 256604
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 25
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Limitador Automático de Audio 250-LA - Solidyne; Buenos Aires
- Shape
- Rack
- Dimensions (WHD)
- 483 x 88.8 x 330 mm / 19 x 3.5 x 13 inch
- Notes
-
- Limitador de audio de acción automática, cuenta con:
- Semiconductores de silicio
- Módulos enchufables
- Recuperación automática programable
- Limitación asimétrica ajustable hasta 120%
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- -- Schematic
- Author
- Model page created by Jorge Juan Stark. See "Data change" for further contributors.
