FL-50B

FL-50B; Sommerkamp (ID = 1345369) Commercial Tr

FL-50B; Sommerkamp (ID = 1345370) Commercial Tr

FL-50B; Sommerkamp (ID = 1345371) Commercial Tr

FL-50B; Sommerkamp (ID = 1345372) Commercial Tr
FL-50B; Sommerkamp (ID = 2500155) Commercial Tr
Use red slider bar for more.
FL-50B; Sommerkamp (ID = 2500155) Commercial Tr
Sommerkamp: FL-50B [Commercial Tr] ID = 2500155 1188x465
Select picture or schematic to display from thumbnails on the right and click for download.
For model FL-50B, Sommerkamp:
Rivista 'Sperimentare' dicembre 1975.

Country:  Germany
Manufacturer / Brand:  Sommerkamp
alternative name

Sommerkamp El. Schweiz
Year: 1973 ?? Category: Commercial Transmitter (TX not Transceiver)
Valves / Tubes 7: 6BA6 12AT7 6BA6 6CB6 12BY7 6JS6A 6U8
Semiconductors (the count is only for transistors) 2: 2SC372 2SC372
Main principle Transmitter
Wave bands Short Wave (SW only)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: FL-50B - Sommerkamp
Material Metal case
Dimensions (WHD) 334 x 153 x 262 mm / 13.1 x 6 x 10.3 inch
Notes

The FL-50B SSB transmitter is a compact, high performance desk top amateur transmitter with CW, AM and SSB modes. On all modes, except AM, this transmitter works at an input of 50 Watts PEP on all bands from 80 to 10 meters. AM consists of transmitted carrier and one sideband. The SSB signal is generated by a crystal filter.

Manufactured by Yaesu-Musen for Sommerkamp.

Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Source of data -- Original-techn. papers.

Model page created by Mauro Grando. See "Data change" for further contributors.
