For model FR-50B, Sommerkamp

Country:  Germany
Manufacturer / Brand:  Sommerkamp
alternative name

Sommerkamp El. Schweiz
Year: 1967 ? Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Valves / Tubes 8: 6BZ6 6BE6 6BA6 6BA6 6BA6 6CB6 12AT7 6BM8
Semiconductors (the count is only for transistors) 2:
Main principle Superhet, double/triple conversion; ZF/IF 5173,9/455 kHz; 2 AF stage(s)
Wave bands Short Wave (SW only)
Details
Power type and voltage Alternating Current supply (AC) / 100; 110; 117; 200; 220; 235 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: FR-50B - Sommerkamp
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 335 x 153 x 260 mm / 13.2 x 6 x 10.2 inch
Notes Sommerkamp KW-Empfänger FR-50B.
Empfängt das 80-, 40-, 20- und 15-Meter-Band in 600 kHz breiten Bereichen, 28-29,2 MHz in einem Bereich; Betriebsarten: AM, SSB, CW.
Von Yaesu für Sommerkamp gefertigt.
Net weight (2.2 lb = 1 kg) 7.2 kg / 15 lb 13.7 oz (15.859 lb)
