FLDX-500 ; Sommerkamp (ID = 744473) Amateur-T
Sommerkamp: FLDX-500 [Amateur-T] ID = 744473 900x467
Select picture or schematic to display from thumbnails on the right and click for download.
For model FLDX-500, Sommerkamp:
Aus Katalog 1974 der Fa. Richter & Co.; Hannover

Country:  Germany
Manufacturer / Brand:  Sommerkamp
alternative name

Sommerkamp El. Schweiz
Year: 1968 Category: Amateur Transmitter (only)
Valves / Tubes 13: 6AN8 6U8 6U8 12AU7 12AT7 6BA6 6AW8 12AU7 6CB6 12BY7A 6JS6A or 6JS6C 6JS6A or 6JS6C 6BM8 VR150
Semiconductors (the count is only for transistors) 3:
Main principle Transmitter
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 100-235 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: FLDX-500 - Sommerkamp
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 160 x 290 mm / 14.6 x 6.3 x 11.4 inch
Notes AM, CW, SSB transmitter for 80, 40, 20, 15 and 10 meter amateur bands. Final amplifier uses two 6JS6 tubes in parallel. Matches FRDX-500 receiver. Copy of YAESU FLDX-400 for Sommerkamp.
Net weight (2.2 lb = 1 kg) 18 kg / 39 lb 10.4 oz (39.648 lb)
Price in first year of sale 1,450.00 DM
Collectors' prices
Source of data - - Manufacturers Literature
Mentioned in Katalog H.Bauer 1968

Model page created by Götz Linss. See "Data change" for further contributors.
