For model 7FC-89W, Sony Corporation; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony Corporation; Tokyo
Year: 1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
schematic requested
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 7FC-89W - Sony Corporation; Tokyo
Material Various materials
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 136 x 195 x 155 mm / 5.4 x 7.7 x 6.1 inch
Notes

Sony 7FC-89W
upright clock radio in woodgrain type cabinet with aluminium side panels with in the beginning Telechron manuel movement Made in USA, at later stage Far East movements were built-in. Tuning dial drum with window, sleep function, speaker grill at left hand side cabinet.

Net weight (2.2 lb = 1 kg) 1.280 kg / 2 lb 13.1 oz (2.819 lb)

Model page created by Eckhard Wegner. See "Data change" for further contributors.
