For model 79, Sparton of Canada; London, ON:
By courtesy of guest Harry Ducker, Ayr, Ontario, Canada.

Country:  Canada
Manufacturer / Brand:  Sparton of Canada; London, ON
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6A8G 6K7G 6H6G 6K5G 6U5 or 6G5 6F6G 5Y4G
Main principle Super-Heterodyne (Super in general); ZF/IF 456 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 79 - Sparton of Canada; London, ON
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes The Sparton model 79 has reception for broadcast 550 to 1700 kc (kHz) and short waves 6 to 18 mc (MHz).
Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Canada Schematics Sparton page 64

Model page created by Dirk Taekels. See "Data change" for further contributors.
