• Year
  • 1970 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 244444
    • Brand: Radiola

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radiola 9853 - SR, Svenska Radioaktiebolaget
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Notes
  • Kleine Stereo-Compact-Anlage mit Plattenspieler und 2 Lautsprecherboxen.
    Radioteil mit 5 UKW-Festsender-Programm-Tasten.

  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
