• Country
• Italy

• Manufacturer / Brand
• SRE - Scuola Radio Elettra, Torino

• Year
• 1980 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 303023

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 3 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Tester 981 - SRE - Scuola Radio Elettra,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 110 x 50 x 170 mm / 4.3 x 2 x 6.7 inch

• Notes

• Tester per misure in Volt AC/DC, Ampere DC, Ohm.
  Portate:
  0,1/1/10/100/1000 mA DC
  1/3/10/30/100/300/1000 VDC
  3/10/30/100/300/1000 VAC
  0- 2 MΩ, in due portate x10, x1000
  misura dB: -12 +12
  Sensibilità strumento: 20000 Ω/V DC, 6325 Ω/V AC

• Literature/Schematics (2)
• Riparazioni - Scuola Radio Elettra

• Author
• Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
