8 Transistor High Fidelity SR-H506L

8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1299314) Radio 8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1299628) Radio
8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1299655) Radio 8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568727) Radio
8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568728) Radio 8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568729) Radio
8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568731) Radio 8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568734) Radio
8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568736) Radio 8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1568737) Radio
Use red slider bar for more.
8 Transistor High Fidelity SR-H506L; Standard Radio Corp. (ID = 1299314) Radio
Standard Radio Corp.: 8 Transistor High Fidelity SR-H506L [Radio] ID = 1299314 933x840
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8 Transistor High Fidelity SR-H506L, Standard Radio Corp. (SR), Tokyo

Country:  Japan
Manufacturer / Brand:  Standard Radio Corp. (SR), Tokyo
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA234 2SA101 2SA101 2SB175 2SB175 2SB172 2SB178 2SB178
Main principle Superheterodyne (common); ZF/IF 455 kHz; 6 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Dry Batteries / 3 x 1,5 R20, 4,5 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: 8 Transistor High Fidelity SR-H506L - Standard Radio Corp. SR, Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 240 x 140 x 52 mm / 9.4 x 5.5 x 2 inch
Notes

3 Band 8 Transistor Portable Radio.
Range LW 150 - 370 KC, MW 535 - 1605 KC, SW 6 - 18 MC.

Schaltbare Skalenbeleuchtung, 2 Lautsprecher 80mm und 90mm, Teleskopantenne für KW.

Net weight (2.2 lb = 1 kg) 1.150 kg / 2 lb 8.5 oz (2.533 lb)
Source of data -- Collector info (Sammler)

Model page created by Franz Scharner. See "Data change" for further contributors.
